| Model | BPGQ-300 | BPGQ-400 | BPGQ-600 | BPGQ-800 | |||
| Quantity of Spindles | pcs | 1 | 1 | 1 | 1 | ||
| Belt Width | mm | 321 | 421 | 621 | 821 | ||
| Blade Diameter | mm | Φ150~Φ300 | Φ150~Φ300 | Φ150~Φ300 | Φ150~Φ300 | ||
| Max. Processing Width | mm | 300 | 400 | 600 | 800 | ||
| Max. Processing Thickness | mm | 50 | 50 | 50 | 50 | ||
| Range Of Cutting Speed | m/min | 1~6 | 1~6 | 1~6 | 1~6 | ||
| Spindle Motor Power | kW | 18.5 | 18.5 | 18.5 | 18.5 | ||
| Belt Motor Power | kW | 1.5 | 1.5 | 1.5 | 1.5 | ||
| Lifting Motor Power | kW | 0.55 | 0.55 | 0.55 | 0.55 | ||
| Total Power | mm | 20.55 | 20.55 | 20.55 | 20.55 | ||
| Overall Dimensions(L*W*H) | kg | 1900×1400×1700 | 1900×1700×1700 | 2100×1600×1800 | 2100×1900×1800 | ||
| Weight | kg | 1100 | 1200 | 1300 | 1500 | ||
